0:00
Have you ever wasted hours
0:01
troubleshooting a PLC program because of
0:03
confusing tag names? Or inherited a
0:06
system where deciphering the code felt
0:08
like breaking an ancient cipher? Poor
0:10
naming conventions can turn a simple
0:12
maintenance task into a nightmare. In
0:15
this video, I'll show you how proper PLC
0:17
naming can save you time, reduce errors,
0:20
and make you a more effective
0:21
programmer. PLC naming conventions. Five
0:25
essential steps for clean, efficient
0:27
code. A well ststructured PLC program is
0:30
the cornerstone of reliable and
0:32
maintainable automation. While the logic
0:35
itself is critical, an often overlooked
0:38
aspect is the naming convention used for
0:40
tags, routines, and other components. A
0:44
consistent and descriptive naming
0:46
convention can drastically improve
0:48
troubleshooting, collaboration, and the
0:51
overall longevity of a system. Here are
0:54
some best practices to follow. Detailed
0:56
information contained in this video can
0:58
be found at accccclautomation.ca.
1:02
Why do naming conventions matter?
1:06
Clear names make the code easier to read
1:08
and understand, not just for you, but
1:11
for anyone else who might work on the
1:13
system. Troubleshooting. When a machine
1:16
is down, you need to find the problem
1:18
fast. Descriptive names like motor
1:21
status running are far more helpful than
1:23
generic names like MTR1
1:26
stat R. Scalability. A good convention
1:30
makes it easier to create new components
1:32
and expand the system without
1:34
introducing confusion. Collaboration.
1:38
When multiple people are working on the
1:39
same project, a standardized naming
1:42
system ensures everyone is on the same
1:47
Naming conventions can act as a form of
1:50
reducing the need for extensive separate
1:53
documentation that can quickly become
1:55
outdated. Key principles for naming.
1:58
One, be descriptive and clear. Avoid
2:01
abbreviations or acronyms that aren't
2:03
widely understood. If you must use
2:05
abbreviations, make sure they are
2:07
documented. A tag name should tell you
2:09
what the tag does without needing to
2:11
look at the code. For example, pump one
2:14
start push button is much better than
2:18
Two, use a consistent structure. Decide
2:21
on a structure and stick to it. A common
2:24
approach is a hierarchical structure
2:26
such as location equipment description
2:28
type. Example line 100 conveyor start
2:33
PB. Three, choose a case convention.
2:36
Pick a case style and use it uniformly
2:39
throughout the project. Common options
2:41
include Pascal case, camelc case, and
2:43
snake case. Many programmers prefer
2:46
snake case for its readability. The key
2:49
is consistency throughout your project.
2:52
Four, incorporate data types and
2:54
purpose. Include a prefix or suffix that
2:57
indicates the data type or the tag's
2:59
purpose. This immediately tells a
3:02
programmer how the tag is being used.
3:05
Common prefixes, suffixes, in for
3:08
inputs, out for outputs, stat for
3:11
status, ALM for alarms, and CMD for
3:16
Example, tank level, sensor in or motor
3:20
speed, feedback, analog. Five, use
3:24
consistent abbreviations.
3:26
If you need to use abbreviations, create
3:28
a list and use them consistently.
3:30
For example, MTR for motor, VLV for
3:34
valve, PB for push button, LS for limit
3:37
switch. Make sure these are documented
3:39
in a central location for new team
3:41
members. Let's look at some examples to
3:43
see these principles in action. Compare
3:46
these bad and good naming examples. Bad
4:00
start PB. The good name is descriptive
4:04
and tells you the location equipment and
4:07
function of the tag. Bad timer good
4:14
timer accumulated time. The good name
4:18
clarifies the purpose of the timer and
4:20
what the value represents.
4:23
Bad valve estatus. Good tank drain
4:28
valve. Status open ls.
4:33
The good name uses a clear structure and
4:35
identifies the specific type of sensor.
4:37
Bad temp. Good oven temperature. Set
4:44
The good name distinguishes between the
4:46
actual temperature and the desired set
4:48
point and indicates it's an analog
4:50
value. Creating a solid naming
4:53
convention for your PLC projects is a
4:55
crucial investment that pays dividends
4:57
in the long run. It's a simple change
5:00
that can lead to more organized,
5:01
readable, and professional code. Taking
5:05
the time to establish and enforce a
5:07
standard will make your projects easier
5:09
to manage, troubleshoot, and maintain
5:11
for years to come. Let's recap the five
5:14
essential steps for creating effective
5:16
PLC naming conventions. Step one, be
5:20
descriptive and clear. Use names that
5:22
clearly describe what the tag does like
5:25
pumpto start push button instead of PB1.
5:30
Step two, use a consistent structure.
5:33
Follow a hierarchical pattern like
5:36
location do equipment description
5:39
type to maintain organization across
5:41
your program. Step three, choose a case
5:45
convention. Whether it's Pascal case,
5:48
camelc case, or snake case, consistency
5:51
is key for readability.
5:53
Step four, incorporate data types and
5:56
purpose. Use prefixes or suffixes like
5:59
in, out, or stat to immediately indicate
6:03
how a tag is being used. Step five, use
6:07
consistent abbreviations.
6:09
If you must abbreviate, document them
6:11
and use them consistently throughout
6:13
your project. Following these five steps
6:16
will lead to more maintainable,
6:18
readable, and professional PLC programs
6:20
that save time during troubleshooting
6:22
and make collaboration easier.
6:25
By implementing these five essential
6:27
steps, you'll create more maintainable
6:29
and professional code that saves time
6:32
during troubleshooting and makes
6:34
collaboration easier. If you found this
6:36
video helpful, please like and subscribe
6:39
for more automation tips and best
6:43
