The Trumeter ADM100 Series Graphical Panel Meters provide the visual representation of an analog meter and the accuracy of a digital meter all in one unit.
These meters feature a programmable bar graph and alarms to immediately alert operators when a parameter is out of range. In addition, a four-character messaging area displays custom messages, alarms and annunciators.

Every meter is configurable to measure voltage, current or frequency. The M100-Lx model is for use with a low voltage power supply, and the ADM100-Hx is for use with mains power. Both models offer two LCD options – positive LCD for bright conditions or negative LCD for dark environments.
We will be looking at unboxing the unit, powering it up, installing the software and setting and communication to the Trumeter AMD100 Series Graphical Panel Meter. Let’s get started. Continue Reading!
