BRX (Do-More) PLC PID Ramp Soak Profile

The purpose of a ramp soak profile is to make gradual, controlled changes in temperature (Ramp), followed by a temperature hold (Soak) period.
We will be using our Do-More Proportional-Integral-Derivative PID Instruction with PWM output that we looked at last time to apply the ramp/soak profile. This will be done on the BRX Do-More PLC.
Using the immersion heater in a cup of water to keep the temperature at a constant value, we will be adjusting the profile of the temperature as we increase the setpoint (Ramp) and hold that set point for a predetermined time. (Soak) We will then decrease that temperature back to the original setting. (Ramp)
BRX (Do-More) PLC PID Ramp Soak Profile
We will be modifying our existing program from our PID with PWM Output post. Let’s get started.
