Click PLC High Speed Counting – Part 2

The Ethernet Click PLC high speed counter has seven different modes of operation. In Part 1 we discussed the High Speed Count Mode, Interval Measurement Mode,
Duration Measurement Mode and Frequency Measurement Mode.

This 100 KHz counter can accept Up, Down, Up/Down, Pulse/Direction or Quadrature (with Z) inputs.
We will be looking at the last three different high speed counter modes available in the click. (External Interrupt, Pulse Catch, Filter) This is all setup through a user friendly graphical user interface. We will also combine the Frequency Measurement and the High Speed Count in one application. Let’s get started! Keep on Reading!
