C-More Micro HMI Object Text – EA3 Series

The C-More Micro HMI Panel software uses virtual components called Objects. Five different text objects are available for your industrial human-machine interface. (HMI) The static text will place words on your HMI page. Lookup text will display a message corresponding to a value in a tag register. The dynamic text will display the ASCII (American Standard Code for Information Interchange) equivalent of the information in the tag register specified. Scroll text will display information too large to display in the area assigned. This will move the information in the display area so the entire message can be seen. Text entry will allow the user through a popup keypad to enter ASCII characters into a tag register.
C-More Micro HMI Object Text - EA3 Series
We will now look at all five of these text objects in our HMI micro panel. A new page will be made to show all of the text object functions and operations. Let’s get started. Continue Reading!
