The Productivity Series 2000 and 3000 CPUs and remote controllers have OLED/LCD displays. The data can be system errors and information or user-defined messages programmed through ladder logic. Operators, maintenance, or programmer can use this information for running conditions, troubleshooting, or other items for the PLC system.
We will be looking at the CPU OLED/LCD on the productivity 2000 PLC. The eight control buttons will display the inputs and output for troubleshooting. System parameters like the real-time clock can also be set using the CPU display and control buttons. Custom messages displayed will be programmed in ladder logic. This will include scrolling messages and displaying tag information. Let’s get started. Keep on Reading!
