The Machine Simulator (MS) is part of the EasyPLC software suite. It has many built-in machines that can be programmed. The gantry loader is one of these machines. It will pick up metal boxes from a conveyor and place two on a wooden pallet. The Click PLC will be used to program this virtual machine.
Using the Click Plus PLC, we will connect the simulator to the gantry loader machine. This will be done using Modbus TCP (Ethernet) for communications. Using the five steps for program development we will show how this is programmed. The logical sequence step will include a flow chart and a sequence of operations. The sequence of operations will be done using indirect addressing in the Click PLC. Let’s get started. Keep on Reading!
